STMicroelectronics is introducing two ultralow power global shutter image sensors designed for systems that need continuous visual awareness without a large energy budget. The VD55G4 and VD65G4 are built for embedded vision tasks where the sensor remains active while the rest of the system stays idle.
Both parts are compact CMOS image sensors used to detect activity, track motion, or capture basic scene data in low-power electronic devices. In a typical design, they sit at the front of the vision pipeline, watching the scene and passing control to a microcontroller when something changes. The devices operate at around 800 by 700 resolution at roughly 10 frames per second, which places them firmly in the category of sensing rather than high-resolution imaging. The emphasis is on keeping a visual input running continuously without placing a heavy load on the battery.
Event-Driven Operation Instead Of Continuous Streaming
The sensors include a detect-and-wake mode that changes how image data is handled at system level. Instead of sending a continuous stream to a processor, they monitor the scene locally and only trigger the host when activity is detected. This allows the rest of the system to remain in a low-power state for long periods. In wearable or battery-powered designs, that can have a direct impact on runtime, especially where the device is expected to respond instantly to user interaction or environmental changes. It also reduces the need for constant processing, which is often where most of the power is consumed in small vision systems.
Global Shutter Without The Usual Power Penalty
Both sensors use a global shutter architecture, capturing the full frame at once rather than scanning line by line. That removes motion distortion, which is important in applications such as gesture detection or positional tracking. Global shutter designs are typically avoided in low-power systems because of their higher power requirements. Here, the architecture has been tuned for lower consumption, which brings that capture method into systems that would normally rely on rolling shutter alternatives. The result is a cleaner signal for basic vision tasks without requiring a more complex imaging pipeline.
Designed For Microcontroller-Level Vision Systems
The VD55G4 and VD65G4 are intended to connect directly to low-power microcontrollers and simpler system-on-chip platforms. That reduces system complexity and removes the need for a higher-end processor in applications that only require basic visual awareness. In practical terms, the sensor can run alongside an MCU, handle initial detection, and pass on only the relevant events. This setup fits designs such as glance detection in wearables, presence sensing in home devices, or low-power monitoring nodes where the system is expected to stay active for long periods.
ST is also supporting the devices with development boards, camera modules, and software tools to help bring up prototypes more quickly.
A Fit For Compact And Energy-Constrained Designs
The sensors are built on a 3D stacked process combining 65 nm and 40 nm technologies and are manufactured on 300 mm wafers. The small optical format and integrated processing keep the footprint low, which is important in space-constrained products. They are aimed at designs where vision needs to be available continuously, but only a small amount of data is actually required at any given time. That includes battery-powered devices and systems using energy harvesting, where every part of the power budget has to be managed carefully.
Learn more and read the original announcement at www.st.com
Technology Overview
The VD55G4 and VD65G4 are ultralow power global shutter CMOS image sensors designed for embedded vision systems. They operate at approximately 800 by 700 resolution at around 10 frames per second and include a detect-and-wake mode for event-driven operation. The sensors are built on a 3D stacked 65 nm and 40 nm process and interface with low-power microcontrollers.
Frequently Asked Questions
Where would these sensors typically be used in a system?
They are placed at the front of a vision subsystem, monitoring a scene and triggering a microcontroller or processor when activity is detected.
Do the VD55G4 and VD65G4 continuously stream image data?
No, they support a detect-and-wake mode where the sensor monitors the scene locally and only sends data when a change is detected.
What type of shutter do these sensors use?
They use a global shutter architecture, capturing the entire frame at once to avoid motion distortion.
Image credit: STMicroelectronics
