RISC-V Vector Engine Helps to Address 128 Qubits with One Instruction

RISC-V is arguably going to become the future of CPU ISAs thanks to its customization capabilities, open-source nature, and growing support. Now, researchers have demonstrated how a single vector instruction can address up to 128 qubits for future quantum computers.

Researchers Demonstrate RISC-V Vector Addressing of 128 Qubits

RISC-V is arguably going to become one of the most important CPU ISAs thanks to its customization capabilities, open ISA, and growing support. Now, researchers have demonstrated how a single vector instruction can address up to 128 qubits for future quantum computers.

Quantum computing has great promise in being able to solve complex problems much faster than traditional computers thanks to the ability to evaluate many different possibilities simultaneously.

However, current quantum computing devices suffer from numerous challenges including the need for extremely low temperatures, the requirement for careful maintenance to reduce decoherence, and the need for large amounts of classical computational power to configure and control quantum hardware.

Even though researchers continue to make advances in the field of quantum computing, one challenge that remains is the bottleneck between the quantum processor and the classical processor responsible for controlling it. For example, a quantum circuit may only take a few microseconds to execute, but the associated classical control, measurement, and processing can increase overall execution time to several milliseconds.

{{TCC_CORE:embed_video[ID=1Y82U450zcI]}}

Recognizing these challenges, researchers from MIT and collaborators recently published their findings on a new RISC-V-based quantum control engine capable of addressing up to 128 qubits using a single vector instruction. The new architecture, based on the RISC-V Vector (RVV) extension, helps reduce the complexity of controlling large quantum circuits while introducing a hardware halt-resume mechanism that allows execution to restart approximately 80 ns after a mid-circuit measurement. This is particularly useful for hybrid quantum-classical algorithms that require frequent interaction between the quantum processor and its classical controller.

To evaluate the architecture, the researchers implemented their design on an Intel FPGA and compared it against conventional quantum control systems. According to the researchers, the new architecture achieved program execution speeds of up to 2.52× faster than existing control architectures, with performance improvements becoming greater as the number of qubits increased.

The ability to pack multiple quantum operations into a single vector instruction also allows for much greater parallelization, especially for workloads containing large numbers of independent two-qubit gates. As a result, the researchers demonstrated an execution speed-up of up to 52× for the Bell-8 benchmark by executing an entire layer of independent two-qubit operations using a single vector instruction.

However, the researchers also noted that not every quantum algorithm benefits equally from the architecture. Algorithms with deep sequential gate dependencies, such as the Quantum Approximate Optimisation Algorithm (QAOA) and Quantum Fourier Transform (QFT), offer fewer opportunities for vectorisation, meaning the performance gains are more limited despite the specialized hardware.

Finally, the FPGA implementation demonstrated that the architecture scales efficiently as additional qubits are added. According to the researchers, performance increased approximately linearly while maintaining relatively low FPGA resource usage, suggesting that the architecture could support larger fault-tolerant quantum computing systems without requiring major redesigns.

Could RISC-V Become the Future ISA for Quantum Computing?

When it comes to cutting-edge research, researchers have gradually been shifting towards open platforms, open standards, and collaborative development. Over the past decade, this approach has accelerated innovation by allowing engineers and researchers around the world to build upon each other's work instead of developing entirely new platforms from scratch.

One of the biggest advantages of an open ISA such as RISC-V is that anyone can implement it without paying licensing fees or royalties. This allows companies, universities, and researchers to develop custom processors while remaining compatible with the same instruction set architecture. Instead of reinventing the wheel, developers can focus on adding the features that matter most to their application.

This is particularly important for quantum computing. Since the field is still evolving, researchers often need specialised hardware capable of supporting new quantum control methods. RISC-V allows custom instructions to be added while maintaining compatibility with existing software tools and classical processors, making it well suited for integrated quantum-classical computing systems.

Another major advantage is that RISC-V processors can be rapidly deployed onto FPGA development platforms. This allows engineers to prototype, test, and refine new processor architectures long before committing to expensive semiconductor fabrication, significantly reducing both development cost and design time.

With all of these factors considered, it is easy to see why RISC-V has become an attractive platform for quantum computing research. Its open ISA, ability to support custom instructions, and compatibility with existing development tools allow researchers to experiment with new quantum control architectures without the licensing restrictions associated with many proprietary processor designs.

Whether RISC-V ultimately becomes the dominant ISA for quantum computing remains to be seen. The quantum computing industry is still in its early stages, and a variety of hardware and software approaches are still being explored. However, because RISC-V is flexible, royalty-free, and easily adapted to specialized applications, it is becoming a strong candidate for researchers developing the next generation of quantum computing systems.
